Hero Honda New Karizma ZMR PGM Fi. New Karizma ZMR Fi is powered by the same 223cc engine but has been altered by Hero Honda engineers, now it gets fuel injection which has increased the maximum power to 17.6 Bhp at 7000 rpm which is up by 0.6 Bhp and maximum torque has been increased by .15 Nm which is now 18.35 Nm @ 6000 rpm.
VEHICLE SUMMARY
Name: New Karizma ZMR
Model: PGM Fi
Type: Sports
Top Speed: 126kph
ENGINE SPECIFICATIONS
Displacement: 223cc
Engine: 4 Stroke, Fuel Injection, OHC
Maximum Power: 17.6 Bhp @ 7000 rpm
Maximum Torque: 18.35 Nm @ 6000 rpm
Gears: 5 Speed
Clutch: Multiplate Wet
Bore: 65.5
Stroke: 66.2
No. of Cylinders: 1
Cylinder Configuration: NA
Engine Block Material: NA
Chassis Type: Tubular Single Cradle, Diamond Type
Cooling Type: Liquid Cooling
Carburetor: NA
Motor Power: NA
Motor Range: NA
Paddling Arrangement: NA
0 to 60: 3.70 sec.
DIMENSIONS
Length: 2110.00 mm
Width: 805.00 mm
Height: 1175.00 mm
OTHER SPECIFICATIONS
Weight: 159.00 kg
Ground Clearance: 159.00 mm
Fuel Tank: 16.00 liters
Wheelbase: 1350.00 mm
Turn Circle: 2.50 meters
Electrical System: 12V - 7 Ah - 232 W Alternator
Headlamp: 12V - 35W/35W - Halogen
Battery Type: Maintenance Free
Battery Voltage: 6V
Battery Capacity: 6Ah
Battery Charger Type: NA
Horn: NA
Wheel Type: Die Cast Black Alloys
Wheel Size: Front - 80/100x18 47P Rear - 100/90 18 56P mm
Tubeless: v
Colors: Pearl White, Sports Red, Vibrant Blue, Moon Yellow & Panther Black
ACTIVE AND PASSIVE SAFETY
Suspension( Front): Telescopic Hydraulic Shock Absorbers
Suspension( Rear): 5 Step Adjustable iGRS System
Brakes: 276mm Dia Disc
Brakes( Rear): 240mm Dia Disc
Stand Alarm: ×
COMFORT AND CONVENIENCE
Fuel Guage: Digital
Self Start: v
Tacho Meter: Digital
Trip Meter: Digital-2
Alloys: v
Warranty: 3 Years OR 40000kms Warranty
Speedometer: Digital
Passenger Footrest: v
Passenger Backrest: ×
Step-up Seat: v
Pass-light: v
Low Fuel Indicator: v
Low Oil Indicator: ×
Low Battery Indicator:
High Oil Temp. Indicator: ×
Choked Air Filter Indicator: ×
